ModelCR1PCCR3PCCR5PCCR7.5PCCR10PCCR12PCCR15PCCR20PCCR24PC
Dimensions (LXWXH) (mm)508X812X920660X1016X1220762X1143X1524508X812X1778962X1220X17781062X1220X18781162X1420X18781162X1620X18781362X1620X1960
Nominal Cooling Capacity3.5 kW/1TR10.5kW/3TR17.5 kW/5TR26kW/7.5TR35kW/10TR42kW/12TR52.5kW/10TR70kW/20TR84kW/24TR
Water Reservoir (ltrs.)40 Liters SS-304100 Liters SS-304150 Liters SS-304200 Liters SS-304250 Liters SS-304300Liters SS-304350 Liters SS-304500 Liters SS-304500 Liters SS-304
Compressor TypeRotary 1 No.Rotary 1 No.Scroll 1 No.Scroll 1 No.Scroll 1 No.Scroll 1 No.Scroll 2 No.Scroll 2 No.Scroll 2 No.
CondenserI.G Copper Tubes & Aluminum FinsI.G Copper Tubes & Aluminum FinsI.G Copper Tubes & Aluminum FinsI.G Copper Tubes & Aluminum FinsI.G Copper Tubes & Aluminum FinsI.G Copper Tubes & Aluminum FinsI.G Copper Tubes & Aluminum FinsI.G Copper Tubes & Aluminum FinsI.G Copper Tubes & Aluminum Fins
EvaporatorBrazed plate HX (SS 316 Plates)Brazed plate HX (SS 316 Plates)Brazed plate HX (SS 316 Plates)Brazed plate HX (SS 316 Plates)Brazed plate HX (SS 316 Plates)Brazed plate HX (SS 316 Plates)Brazed plate HX (SS 316 Plates)Brazed plate HX (SS 316 Plates)Brazed plate HX (SS 316 Plates)
RefrigerantR22 / R407CR22 / R407CR22 / R407CR22 / R407CR22 / R407CR22 / R407CR22 / R407CR22 / R407CR22 / R407C
Water Circulation Pump20 LPM @ 2 kg/ cm^240 LPM @ 2 kg/ cm^270 LPM @ 2 kg/ cm^2100 LPM @ 2 kg/ cm^2120 LPM @ 2 kg/ cm^2150 LPM @ 2 kg/ cm^2180 LPM @ 2 kg/ cm^2240 LPM @ 2 kg/ cm^2300 LPM @ 2 kg/ cm^2
Water Connections0.75″ BSP1″ BSP1″ BSP1.25″ BSP1.25″ BSP1.25″ BSP1.5″ BSP1.5″ BSP2″ BSP
Temperature ControllerMicroprocessor Based Temperature Controller
Temp. Stability(+-1) degree Celsius
Total Input1.3kW Single phase, Ac, 50Hz3.3 kW Three phase, Ac, 50Hz6 kW Three phase, Ac, 50Hz9 kW Three phase, Ac, 50Hz12 kW Three phase, Ac, 50Hz14 kW Three phase, Ac, 50Hz18 kW Three phase, Ac, 50Hz24 kW Three phase, Ac, 50Hz28 kW Three phase, Ac, 50Hz
